  UNO-2473G
  Intel® Atom™ Regular-Size Automation Computer w/ 4 x GbE, 3 x mPCIe, HDMI/VGA



Main Features

  • 4th Generation Intel® Atom™ Processor up to 1.91GHz with 4GB DDR3L Memory
  • 4 x GbE, 4 x USB 2.0/3.0, 2 x RS-232, 2 x RS-422/485, 1 x VGA, 1 x HDMI, Audio
  • Comprehensive Palm, Small, Regular-size form-factor
  • Compact with Fanless Design
  • Rubber Stopper Design with Captive Screw
  • Diverse system IO and Isolated Digital IO by iDoor Technology
  • Supports Fieldbus Protocol by iDoor Technology
  • 3G/GPS/GPRS/Wi-Fi Communication by iDoor Technology
  • Supports MRAM by iDoor Technology
  • Chassis Grounding Protection
  • LAN Redundancy (Teaming)
  • Fault-Protected RS-485 Transceivers With Extended Common-Mode Range
  •

    Introduction
    Advantech’s UNO-2000 series of Embedded Automation Computers are Fanless with highly ruggedised with an embedded operating system (Windows CE, Windows XPE, Linux- Embedded). It also includes iDoor technology which supports automation feature extensions such as industry fieldbus communication, Wi-Fi/3G, Digital I/O, including Palm, Small, and Regular-size Form-Factors with indicated market segments in terms of entry, value and performance product positioning. Both entry and value Embedded Automation Computers feature specific functions and they are suitable for data gateway, concentrator and data server applications. The performance model can shorten your development time and offer multiple networking interfaces to fulfill a diverse range of requirements.


    Specifications
    Part Number UNO-2473G-E3AE
    Environment  Ingress Protection  IP40
    Vibration Protection Operating, IEC 60068-2-64, 2Grms, random, 5 ~ 500Hz, 1hr/axis (mSATA). Operating,
    IEC 60068-2-64, 0.7Grms, random, 5 ~ 500Hz, 1hr/axis (HDD)
    Operating Temperature  -20 ~ 60°C (-4 ~ 140°F) @ 5 ~ 85% RH with 0.7m/s airflow
    Relative Humidity 10 ~ 95% @ 40° C (non-condensing)
    Shock Protection Operating, IEC 60068-2-27, 50G, half sine, 11ms
    Storage Temperature - 40 ~ 85°C ( -40 ~ 185°F)
     I/O Interface Audio Line-In, Line-Out
    Displays 1x VGA (2560x1600), 1x HDMI (1920x1200)
    Grounding Protection Chassis Grounding
    LAN Ports 4 x RJ45, 10/100/1000 Mbps IEEE 802.3u 1000Base-T Fast Ethernet
    Power Connector 1 x 3 Pins, Terminal Block
    Serial Ports 1x RS-232, DB9, 50~115.2kbps, 2x RS-422/485, DB9, auto flow control, 50~115.2kbps
    USB Port 4x USB Ports (3 x USB2.0, 1 x USB3.0 compliant )
     System Hardware Expansion 3 x Full-size mPCIe slot, mPCIe 2.0
    Graphics Engine Intel® HD Graphics 5000/4400
    LED Indicators LEDs for Power, battery, LAN (Active, Status), Tx/Rx and HDD
    Memory On-board 4GB DDR3L 1333/1600 MHz
    Processor Intel® Atom™ Processor E3845 1.91 GHz Quad Core, 2MB L2
    Storage One mSATA, one drive bay for SATA 2.5" HDD (Compatible with 9.5mm height HDD),
    CFast drive by iDoor Technology (Optional)
    System Chip Integrated Intel 8 Series Chipset
    Watchdog Timer Programmable 256 levels timer interval, from 1 to 255 sec
    BIOS  AMI UEFI 128Mbit Flash BIOS
     General Certifications CE, FCC, UL, CCC, BSMI
    Dimensions ( W x D x H ) 252 x 149 x 62 mm (9.9" x 5.9" x 2.4")
    Enclosure Aluminum Housing
    Form factor Regular Size
    Mounting Stand, Wall, VESA (Optional), Din-rail (Optional)
    OS Support Microsoft® Windows 7/8
    Power Consumption 28W (Typical), 72W(Max)
    Power Requirement 24VDC ± 20%
    Weight (Net) 1.6kg (3.5lbs)








      * Product image is an approximate guide only.
      * รูปสินค้าเป็นเพียงภาพตัวอย่าง ซึ่งอาจมีรายละเอียดแตกต่างจากสินค้าจริงที่จำหน่าย
