ลบภาพลักษณ์เดิมๆ ของลำโพงเตือนภัยที่ใหญ่และหนัก
ในสภาพแวดล้อมทางอุตสาหกรรม อุปกรณ์เตือนภัยทั้งแบบภาพและเสียงมักจะติดตั้งโดยใช้ลำโพงและไฟสัญญาณแยกกัน ทำให้กระบวนการติดตั้งซับซ้อน อย่างไรก็ตาม QWCD35 Series จาก Qlight พัฒนาฟังก์ชันการเตือนภัยนี้ ให้มีดีไซน์ขนาดกะทัดรัดและลดพื้นที่การติดตั้ง เหมาะแก่สภาพแวดล้อมทางอุตสาหกรรม



1. Key Features of the QWCD35 Series

• Compact Design with High-Efficiency Structure
  – Design utilizing the horn cover as a light-emitting lens
  – Significantly reduced size compared to conventional signal lights
  – Small yet robust structure suitable for space-constrained equipment
• Powerful Sound Options
  – 31 preset warning sounds (up to 115 dB @ 1 m)
  – SD card–based MP3 playback (up to 30 user-defined sound files, max 112 dB)
  – On-site customization via volume control and tone selection switches
• Excellent Dust and Water Protection
  – IP66-rated for dusty or humid outdoor environments
  – Reliable operation in extreme temperature conditions (low-temperature type supports down to –50 °C)
  – Stable performance for outdoor equipment and cold-region installations
• Enhanced Visual Warning Performance
  – Strobe flashing mode with 60–80 flashes per minute for high visibility
• Safety Compliance & Certifications
  – RoHS-compliant design
  – CE certified for European markets
  – UL certified for 12–24 V models

2. Recommended Applications & Target Users

• Manufacturing plants with frequent production line reconfiguration
  – Wireless control enables immediate expansion when lines are relocated or equipment is added
• Environments where wiring installation is difficult
  – High locations, confined spaces, and mobile equipment such as AGVs, carts, and forklifts
• Industrial sites requiring alerts for equipment status changes
  – Equipment faults, operation completion, or process stoppage
  – Applicable to CNC machines, laser cutters, injection molding machines, assembly lines, logistics and packaging lines, and inspection equipment
• Sites with high noise levels or limited operator visibility
  – Enhanced safety through powerful combined visual and audible warnings

“See It and Hear It at Once — QWCD35,
An Industrial All-in-One Alarm Solution Combining Visual and Audible Signaling”

Cr. https://www.qlight.com/en/board/news/1341/
