Products > Advantech > Remote I/O&Wireless Sensing Modules

WISE-2410

LoRaWAN Wireless Condition Monitoring Sensor

Main Features

LoRaWAN wireless connectivity
Built-in 3-axis accelerometer and temperature sensor
Computing eigenvalues on board (e.g VRMS, ARMS, Peak, Kurtosis, Crest factor, Skewness and Standard Deviation values)
Battery-powered, no wiring installation needed
Easy setting with user friendly interfaces on WISE Studio
Compliant with ISO 10816-3
Support wide temperature -20 ~ 85 °C
IP66 enclosure design

Introduction

WISE-2410 is a LoRaWAN wireless conditional monitoring sensor integrated with ARM Cortex-M4 Processor, LoRa transceiver, 3-axis accelerometer and temperature sensor. Battery life cycle is 2 years with IP66 enclosure.

Specifications
Part Number		WISE-2410-NA
Wireless Communication	Topology	Star (LoRaWAN)
	Frequency Band	US 902-928 (MHz); EU 863-870 (MHz); TW 920-925 (MHz); JP 920-928 (MHz)
	Spreading Factor	7~12
	Transmit Power	Up to +18dBm
	Data Rate	50 kbps at FSK mode EU868;21.9 kbps at SF7 mode US915;5.47 kbps at SF7 mode JP923
Vibration Sensor	Axis	X-Y-Z
	Frequency Range	10~1000Hz
	Amplitude Range	±2/4/8/16g
	Output Data Rate	3200Hz
	Resolution	10 bit (all g range)
	Sensitivity (TYP.)	31.2mg/LSB
	Noise (MAX. TA = 25°C. 0g)	±150mg
	Nonlinearity	±0.5 %
	Cross-Axis Sensitivity	±1 %
	Sensitivity Change Due to Temperaure	±0.02 %/°C
Temperature Sensor	Operating Range	-20°C ~ 85°C (USB powered); -20°C ~ 50°C (Battery powered)
	Resolution	12 bit
	Accuracy	±2.0°C (±35.6°F) (vertical installation)
Mechanical	Enclosure	IP66
	Mounting	Mounting Stud; Curved Surface Magnet; Adhesives
	Dimension (L x W x H)	42mm x 40.2mm x 84.7mm
General	Power Input	3.6V AA Battery *2pcs (Not included)
	Configuration Interface	Micro-B USB
	Temperature (Operating)	-20°C ~ 85°C (USB powered); -20°C ~ 50°C (Battery powered)
	Temperature (Storage)	-25°C ~ 90°C
	Humidity (Operating)	10% ~ 95% RH
	Humidity (Storage)	5% ~ 95% RH
