Main Features

• Channels:16
• Digital Input;Dry Contact;Logic level 1: close to Iso.GND;Logic level 0: open;Wet Contact;Rated voltage: 24VDC;Logic level 1: 10~30 VDC;and -10~-30 VDC;Logic level 0: -3~3 VDC
• Input Delay:From logic level 0 to 1: 4ms;From logic level 1 to 0: 4ms
• Digital Filter: 3ms
