Products > Advantech > Intelligent Connectivity > Serial Device Servers

EKI-1521I-SC

1-port Device Server with Fiber and WT

Main Features

1 x 10/100 Mbps Ethernet ports and 1 x 100 Mbps Fiber port for LAN redundancy
Provides COM port redirection (Virtual COM), TCP, and UDP operation modes
Supports up to 921.6 kbps and any baud rate setting
Allows a maximum of 5 hosts to access one serial port
Allows a maximum of 16 hosts to be accessed in TCP client mode
Built-in 15-kV ESD protection for all serial signals
Provides rich configuration methods including Windows utility, Telnet console, and web browser
Supports 32/64-bit Windows 2000/XP/Vista/7/8/8.1/10, Windows Server 2003/2008/2012, and Linux

Introduction

The EKI-1521I-SC feature one Ethernet port with RJ45 connector and one fiber port with SC connector to provide a redundant network mechanism that guarantees Ethernet network reliability. These serial device servers are designed to connect RS-232/422/485 serial devices.
