Products > Advantech > Power & Energy > Intelligent Communication Gateways

ECU-1251D

ECU-1251D has an open platform design with Cortex A8 processor, Linux OS, two 10/100 Ethernet ports, and onboard IO - 4DI / 4DO.

Main Features

TI Cortex A8 600MHz CPU with DDR3L 256MB RAM
Onboard IO - 4DI / 4DO
Support web service for remotely on-line monitoring
Firmware update by SD card and online update
Data logger on SD card
Support dual SIM slots for communication redundant
Support MQTT Client for cloud communication
Wide Operating temperature: -40 ~ 70°C

Introduction

ECU-1251D has an open platform design with Cortex A8 processor, two 10/100 Ethernet ports, onboard IO - 4DI / 4DO, and operating temperature range of -40~70°C.With Linux operating system and open Edgelink SDK, which enable to system integrators to develop applications which precisely fit their need.

Specifications
PartNumber	ECU-1251D-R10AA
Environment
Operating Temperature	-40~70 °C (-40~158 °F)
Relative Humidity	5~95% RH (non-condensing)
Storage Temperature	-40~85 °C (-40~185 °F)
Ethernet
Speed	10/100 Mbps
Expansion Function
SIM card slot	Nano SIM card
General
Grounding Protection	Chassis grounding
Programming Language	Linux C
Protocol	OPC-UA Client & Server, DNP3.0 Client & Server, IEC-60870-5-104 Master & Slave, IEC-60870-5-101 Slave, Modbus RTU/TCP Master & Slave, BACNet/IP Server
Hardware
Certification	CE, FCC class A
CPU	TI Cortex A8, 600MHz
LED Indicators	PWR, RUN / ERROR, TX1, RX1, TX2, RX2, Program
Memory	DDR3L 256MB
OS Support	Linux
Power Input	10~30 VDC
Storage	1 x 512MB NAND Flash
Watchdog Timer	15~255 s
I/O Interface
Expansion	1 x Full-size mPCIe Slot
LAN Ports	2 x 10/100 Mbps
Power Connector	1 x 3-Pin Terminal Block
Serial Ports	2 x RS-232/485 (Terminal Block)
Mechanical
Dimension (W x H x D)	140 x 30 x 96.5 mm
Enclosure	SECC
Form Factor	Passive Cooling and Front Accessible
Mounting	Wall, DIN-rail
Power Requirements
Input Voltage	10~30 VDC
Serial Communication
Baud Rate (bps)	50 bps~115.2 kbps
Data Signals	RS-232: TxD, RxD, GND RS-485: Data+, Data-
Wireless Communication
Standard(Technology)	WIFI, LTE
